Split Cooling

ASGA09BMTA - 0.75 Ton



Eco Friendly Wall Mounted Split Air Conditioners



Model No : ASGA12BMTA

Tonnage : 1

Energy Rating : 3 Star

Note:



* Installation charges extra

* Stabilizer not included

Description

Features

Technical Specification

Advanced Technology

More Comfort Airflow

Airflow volume is increased more than current model and comfortable cooling is delivered to every corner of the room.

Performance

High Density Multi-Path Heat Exchanger

Heat exchange performance is substantially improved by the thin high-density heat exchanger and multi-path efficiency technology. High performance grooved piping with expanded heat exchanger area is used.



Blue Fin Condenser

Hydrophillic coated heat exchanger ensures rust resistance for prolonged life.



Powerful Heating

High heating capacity is realized even at low outdoor temperature by mounting a large heat exchanger or large DC rotary compressor and developing high performance inverter PCB



Long Piping with Full Efficiency

Piping can be extended up to the above length for full efficiency with additional charge of gas over and above 7.5 mts. as per Installation manual.



Model

ASGA18BMTA

ASGA24BMTA

EER(W/W)

3.13

3.13

Piping Length

3~15m

3~15m

Airflow(m)

10m

10m

High Capacity Compressor

Compressor capacity higher than machine capacity ensures powerful operation at high ambient temperature.





Automatic airflow adjustment

Powerful mode

Wireless remote controller

Quiet operation

Mildew Resistant Filter

Compressor insulation blanket

Power coated outdoor unit

Advanced Hyper tropical rotary Compressor

Up / down swing flaps

Auto restart

Anti-Corrosion treatment for ODU and heat exchanger fins

Coanda Airflow technology

Coil dry

Inner groove copper tube

Auto-Shut Flaps

Dry Function

Wide angle louvers

Long Pipe

Power airflow dual flaps

Program timer

Auto-Moisture Prevention

Sleep timer

Model

Units

ASGA09BMTA

Star Rating



3

Tonnage

TR

0.75

Cooling capacity

Watts | BTU/hr

2,600 | 8,900

Moisture Removal

ltr/hr

NA

Air flow - High

m3/hr | cfm

640| 380

Power supply

Volts/Ø/Hz



Running Current

Amps

3.73

Power Consumption

Watts

830

EER

W/W

3.13

Indoor Unit Dimensions H x W x D

mm

280x800x215

Indoor Unit Net Weight

kg

7

Outdoor Unit Dimensions H x W x D

mm

536x680x250

Outdoor Unit Net Weight

kg

26

Noise Level (Indoor Unit)

dB

29

Connection Method

Indoor-Outdoor



Connection Pipe Size (Gas/Liquid)

mm

3/8,1/4

Pipe Length Max (Pre-charged)

m

15(10)

Height Difference

m

10

Operating Temperature

Deg. C

46°C

Refrigerant

----

R32

Compressor

----

Hyper Tropical
